Materials/材质说明

· Button/拨柄:PBT UL 94V-0

· Cover/外壳:PBT UL 94V-0 Thermoplastic:Blue,Red,Black 红/蓝/黑

· Base/内芯:PBT UL 94V-0

· Tape Sealed/底部密封:Epoxy resin/环氧树脂

· Terminal Movable Contact/端子导体:Copper Alloy with
  Gold Plated/磷青铜镀金

 · Base2/底座2:PBT UL 94V-0

Specifications/性能说明

· Contact Rating/额定电流
   Switching:25mA,24VDC, Non-Switchin:100mA,50VDC

· Contact Resistance/接触电阻
   Initial初始值:50mΩ Max , After Life Text测试后:100mΩ Max

· Operating Force/拨动力......................1000g Max

· Stroke/拨动行程.............................1.8mm

· Electrical Life/电气寿命..............3000 cycles

· Operation Temperature/使用温度........-40℃ to +85℃

· Storage Temperature/存储温度..........-40℃ to +85℃

· Soldering Information/焊接
   Keep all switch contacts in their off position for all operations在所有操作过程前，请保持开关在“off位置。

· Hand Soldering
   Soldering iron 30W or under at 320°C for 3 sec. max.使用30瓦烙铁控制温度在320℃，焊接时间3秒内。

· Wave Soldering波焊
   Rencommended Solder Temperature at 260°C max. 5 seconds for IC type.焊锡温度260℃，3~5秒钟。

PACKING/包装资料

· All DIP Switches are shipped in standar IC tube.以上产品皆以IC管形式包装。
